- Product Description
-
- Commodity name: HC-110L Horizontal Automatic Packaging Machine
- Commodity ID: HC-110L
HC-110L horizontal packaging machine is an ideal bag packaging equipment that meets the requirements of high-quality packaging and smaller bags. The packaging speed is fast, and it can realize three-side sealing and four-side sealing bags; Packaging needs for various materials such as body and solid objects; roll film forming is used to reduce packaging costs.
Machine parameters:
Items
parameter
Packaging parameters
Smallest bag
50×50mm(Width* Height)
largest bag
110×130mm(Width* Height)
Packing volume
60ml(maximum)
packing speed
≤70 bags/min
mold thickness
60-130ų
Reel outer dia
400mm
Reel diameter
70-80mm
Equipment Specifications
Machine size
2060mm×750mm×1400mm(length*width*height)
total machine weight
500KG
working conditions
environment temperature
-10℃—+55℃
Relative humidity
≤85%(Non-condensing state)
voltage
AC380V、50Hz
working pressure
0.5Mpa
Air consumption
0L/min
monitor rate
2.5Kw
Key words:- Automatic Packaging Machine
- Horizontal packing machine
- packing machine
