Automatic Edible Oil Piston Filling Machine
Category:
High-precision edible oil piston filling machine for sunflower oil, soybean oil, corn oil, olive oil, peanut oil and cooking oil bottles from 100ml to 5L. Servo piston filling, non-drip nozzles, food-grade 304/316L contact parts and complete edible oil filling line options.
- Product Description
-
- Commodity name: Automatic Edible Oil Piston Filling Machine
- Commodity ID: GP3000
High-precision edible oil piston filling machine for sunflower oil, soybean oil, corn oil, olive oil, peanut oil and cooking oil bottles from 100ml to 5L. Servo piston filling, non-drip nozzles, food-grade 304/316L contact parts and complete edible oil filling line options.
Automatic Edible Oil Piston Filling Machine
Grepack automatic edible oil piston filling machine is designed for accurate, clean and stable filling of cooking oil and food oil products, including sunflower oil, soybean oil, corn oil, olive oil, peanut oil, palm oil and vegetable oil in bottles, jerry cans and containers.
Edible oil filling requires clean shut-off, stable volume accuracy and food-grade product-contact parts. This servo piston filling system uses anti-drip nozzles and precise volume control to help reduce oil residue on bottle mouths, avoid product giveaway and keep the edible oil packaging line cleaner during continuous production.
Applications - What edible oils can it fill?
Cooking Oil Products
Sunflower oil, soybean oil, corn oil, vegetable oil, blended oil and household cooking oil.
Premium Food Oils
Olive oil, peanut oil, sesame oil, rapeseed oil, palm oil and other food-grade edible oils.
Bottle & Container Sizes
Small 100ml oil bottles, 500ml to 1L retail bottles, 3L to 5L jerry cans and customized edible oil containers.
Selection note: This page is for edible oil and food-grade oil filling. For engine oil, lubricant oil or chemical oil products, Grepack lubricant oil filling machine or chemical liquid filling machine is normally a better choice.Why choose this edible oil filling machine?
Clean Non-Drip Filling
Anti-drip nozzles help reduce oil strings and residue on bottle mouths, labels and conveyors.
Servo Piston Accuracy
Servo-driven piston filling provides stable volume control for 100ml to 5L edible oil bottles and cans.
Food-Grade Contact Parts
304 stainless steel construction with 316L product-contact parts available for food oil production requirements.
Flexible Line Integration
Can connect with bottle feeding, capping, labeling, coding and carton packing for a complete edible oil filling line.
Key features
1. Siemens PLC and HMI touchscreen for easy filling-volume and speed adjustment.
2. Servo piston filling system for accurate edible oil bottle filling.
3. Non-drip filling nozzles to keep bottles and conveyors cleaner.
4. Suitable for 100ml, 500ml, 1L, 3L, 5L and customized edible oil containers.
5. Food-grade 304/316L stainless steel product-contact parts available.
6. No-bottle no-fill detection, recipe memory and automatic fault alarm for stable production.
Model selection guide
For small edible oil bottles such as 100ml to 500ml olive oil, sesame oil or premium food oil, GP500 series is commonly selected. For 1L sunflower oil, soybean oil and vegetable oil bottles, GP1000 series is suitable for stable production. For 3L to 5L edible oil jerry cans, GP3000 or GP5000 series provides a better filling range and production capacity.
To choose the right edible oil filling machine, send us your oil type, bottle volume, bottle shape, cap type, required output and whether you need labeling, coding or carton packing in the same production line.
Technical parameter
Model GP125 Series / GP500 Series / GP1000 Series / GP3000 Series / GP5000 Series Filling Range 30-125ml, 50-500ml, 100-1000ml, 500-3000ml, 1000-5000ml Filling Nozzle 4 6 8 10 12 Filling Capacity
(Based on 1000ml)<=1200 BPH <=1800 BPH <=2400 BPH <=3000 BPH <=3600 BPH Filling Accuracy <=+/-0.5% Voltage AC220V/380V 50-60Hz, special voltage customizable Air Pressure 0.5-0.8 MPa Power 2.0-3.5KW 2.0-4.0KW 2.5-4.5KW 3.0-5.5KW 3.0-6.5KW Recommended edible oil filling line
A complete edible oil filling line can include bottle unscrambling, servo piston filling, cap sorting, automatic capping, labeling, date coding, carton packing and conveyor connection. Grepack can customize the line according to oil type, bottle size, cap style and target output.
Need an edible oil or cooking oil filling solution? Send us your oil type, bottle size and production speed. Grepack will help you choose the right filling machine and complete packaging line.
Key words:- Edible Oil Filling Machine
- sunflower Oil Filling Machine
- olive oil filling machine
- palm oil filling machine
- Cooking Oil Filling Machine
- coconut oil filling machine
Get Your Free Custom Packaging Solution & Quote
