HC-110 Horizontal Packaging Machine


  • Product Description
    • Commodity name: HC-110 Horizontal Packaging Machine
    • Commodity ID: HC-110

    HC-110 horizontal packaging machine is an ideal bag packaging equipment that meets the requirements of high-quality packaging and smaller bags. The packaging speed is fast, and it can realize three-side sealing and four-side sealing bags; Packaging needs for various materials such as body and solid objects; roll film forming is used to reduce packaging costs.

    Machine parameters:

    Items

    parameter

    Packaging parameters

    Smallest bag

    50×50mm(Width* Height)

    largest bag

    110×130mm(Width* Height)

    Packing volume

     60ml(maximum)

    packing speed

    ≤70 bags/min

    mold thickness

    60-130ų

    Reel outer dia

    400mm

    Reel diameter

    70-80mm

    Equipment Specifications

    Machine size

    2060mm×750mm×1400mm(length*width*height)

    total machine weight

    500KG

    working conditions

    environment temperature

    -10℃—+55℃

    Relative humidity

    ≤85%(Non-condensing state)

    voltage

    AC380V、50Hz

    working pressure

    0.5Mpa

    Air consumption

    0L/min

    monitor rate

    2.5Kw

    Key words:
    • Horizontal Packaging Machine
    • Packing mahcine
    • automatic packing machine
