HC-180SZ/240SZ Zipper Doypack/Stand up Packing Machine
Category:
The zipper Doypack Packing Machine Series is specially designed for the needs of zipper bags. It can also add special functions, such as hanging holes, special-shaped and so on. The series also has a large bag series. To meet the needs of large-dose packaging in zipper stand-up pouch packaging.
- Product Description
-
- Commodity name: HC-180SZ/240SZ Zipper Doypack/Stand up Packing Machine
- Commodity ID: HC-180SZ/240SZ
The zipper Doypack Packing Machine Series is specially designed for the needs of zipper bags. It can also add special functions, such as hanging holes, special-shaped and so on. The series also has a large bag series. To meet the needs of large-dose packaging in zipper stand-up pouch packaging.
The zipper Doypack Packing Machine Series is specially designed for the needs of zipper bags. It can also add special functions, such as hanging holes, special-shaped and so on. The series also has a large bag series. To meet the needs of large-dose packaging in zipper stand-up pouch packaging.
Advantages
1) Omron PLC control, English and man-machine interface, operating easy and simple maintenance.2) Advanced photoelectric sensor tracking system and servo motor pull for precise bag width and position of film.
3) Omron Motion control system: for example, when you change the speed of the main machine on the touch screen, then the speed of the film unwinding, film pulling and piston filling will be changed automatically. with the Omron motion control system, you will save lots of film and time during adjusting, because all speeds are synchronous.
4)the machine with automatic film aligns and adjusts the device
5)Non-stop machine film changing function, when the film runs out, no need to stop the machine with the design of two film rolls, enough film storage, and connection tape detection.
6) Omron's PLC has a remote-control function, if there is a fault during production in your factory, you can send the report to us, and we can fix it online.
Machine parameters:
Model
HC-180SZ
HC-240SZ Pouch Size
90*110mm(Min)
180*260mm(Max)100*120mm(Min)
240*320mm(Max)measuring method
liquid filler /auger filler /weigher
liquid filler /auger filler /weigher Filling capacity
1200ml
2000ml Packing capacity
40-50ppm
30-50ppm Powder
8KW
10kw Air consumption
200NL/min
300NL/min Machine Dimensions
6450mm(L)*1100mm(W)*1400mm(H)
7500mm(L)*1250mm(W)*1550mm(H Weight
2300kg
2800kg Function
Doypack, Shape, Hanging, Hole, Zipper
Doypack,Shape,Hanging Hole,Zipper Key words:- zip pouch packing mahcine
- doypack packing machine
- Stand up Pouch Packing Machine
- zipper doypack packing machine
