Automatic HFFS Twin / Double Sachet Packing Machine
Category:
Twin Packing Machine realize three-side sealing, four-side sealing bag. Twin Sachet Packing Machine is suitable for powder, particle, liquid, paste, solid
- Product Description
-
- Commodity name: Automatic HFFS Twin / Double Sachet Packing Machine
- Commodity ID: HC-180T
Twin Packing Machine realize three-side sealing, four-side sealing bag. Twin Sachet Packing Machine is suitable for powder, particle, liquid, paste, solid
The HC-180T is a high-efficiency HFFS (Horizontal Form Fill Seal) machine featuring Duplex Output Technology. Using a single roll of film, the machine forms, fills, and seals two pouches simultaneously in one cycle. This design doubles your production capacity without increasing the machine's footprint.
Key Features & Advantages
1. Duplex High Speed (1 Cycle = 2 Pouches): The machine utilizes a specialized duplex mold to form two sachets side-by-side on the same film web.Standard Speed: 40-50 cuts/min.
Actual Output: 80-100 pouches/min (since each cut produces 2 bags).
2. Flexible "Twin Pack" Capability: Ideally suited for creating Linked Sachets (Twin Packs) with a perforation line in the middle.
Marketing Application: Perfect for packing Shampoo + Conditioner, or Coffee + Sugar combinations in one connected strip.
3. Independent Dual Filling: Equipped with Two Filling Nozzles that work simultaneously. You can fill the same product in both pouches for high speed, or different products in each pouch for combo packs.
4. Compact HFFS Design: Horizontal flow ensures stable bag forming and high sealing quality (3-side or 4-side seal), ideal for flat sachets requiring a premium look.
Technical specifications:
Model
HC-180T
Type Of Pouch 3/4 side seal Min. Pouch Size 100×80mm Max. Pouch Size 180×210mm Packing Speed
< 60 Pouch/min
Packing Range
Max 200ml
Filling station
2
Power
5kw
Volt
380V 3P 50Hz
Air Consumption
300L/min
Air Pressure
0.6 Mpa
Machine weight
1400kg
Machine dimension
3650×1000×1450mm
Key words:- Horizontal Packing Machine
- automatic packing mahcine
- Linked sachet Packing Machine
- Twin Linked sachet Packing Machine
Provide solutions for your industry and prepare for your choice
