Automatic Liquid Piston Bottle Filling Machine
Category:
Servo automatic liquid piston bottle filling machine for low-to-medium viscosity liquids such as juice, vinegar, syrup, detergent, shampoo, disinfectant and water-based products. 30-5000ml filling range, anti-drip nozzles and +/-0.5% accuracy.
- Product Description
-
- Commodity name: Automatic Liquid Piston Bottle Filling Machine
- Commodity ID: GP1000
Servo automatic liquid piston bottle filling machine for low-to-medium viscosity liquids such as juice, vinegar, syrup, detergent, shampoo, disinfectant and water-based products. 30-5000ml filling range, anti-drip nozzles and +/-0.5% accuracy.
Automatic Liquid Piston Bottle Filling Machine
Grepack automatic liquid piston bottle filling machine is a flexible servo piston filler for low-to-medium viscosity liquid products. It is suitable for juice, vinegar, syrup, liquid detergent, shampoo, disinfectant, hand sanitizer, daily chemical liquids and other water-based or slightly viscous products.
The machine combines servo piston volume control, anti-drip filling nozzles and touchscreen recipe settings, helping factories fill different bottle sizes with clean filling performance, stable accuracy and faster product changeover.
Applications - What Products Can This Liquid Filling Machine Fill?
Food & Beverage Liquids
Juice, vinegar, syrup, edible liquid seasoning, light sauce and similar low-to-medium viscosity food liquids.
Daily Chemical Liquids
Liquid detergent, shampoo, shower gel, hand soap, laundry liquid and other daily-use liquid products.
Water-Based Products
Disinfectant, hand sanitizer, cleaning liquid and non-corrosive chemical liquids after wetted-part review.
Selection note: For highly corrosive liquids such as strong acid, strong alkali or bleach-type products, Grepack anti-corrosive liquid filling machine is usually a better choice. For thick paste, sauce or cream products, choose the dedicated paste, sauce or cream filling machine.
Why Choose This Automatic Liquid Piston Filler?
Flexible Filling Range
Covers 30ml to 5000ml bottle filling needs, from small sanitizer bottles to larger detergent, shampoo and syrup containers.
Servo Piston Accuracy
Servo-controlled piston filling provides repeatable volume adjustment and helps reduce overfilling for high-volume production.
Clean Anti-Drip Filling
Anti-drip nozzles help reduce liquid residue on bottle mouths and conveyors, improving packaging appearance and line cleanliness.
Easy Product Changeover
PLC and HMI recipe settings make it easier to switch between bottle sizes and liquid products with less manual adjustment.
Key Features
1. Siemens PLC and HMI touchscreen for easy operation and filling parameter control.
2. Servo piston filling for accurate liquid filling from 30ml to 5000ml.
3. Anti-drip filling nozzles for cleaner bottle mouths and reduced product waste.
4. No-bottle no-fill detection to reduce leakage and misfilling during operation.
5. 304/316L stainless steel product-contact parts available for food and chemical applications.
6. Can connect with bottle feeding, capping, labeling, coding and packing equipment.
Model Selection Guide
For 30ml to 500ml bottles such as sanitizer, shampoo samples, small juice bottles or light chemical liquids, GP125 or GP500 series is commonly selected. For 1L liquid detergent, vinegar, syrup or cleaning liquid bottles, GP1000 series provides a balanced filling range and speed. For 3L to 5L containers, GP3000 or GP5000 series is more suitable.
Send Grepack your liquid viscosity, foaming level, bottle size, filling volume, target capacity and cap type. We can recommend the right automatic liquid piston filling machine and complete packaging line configuration.
Technical Parameter
Model GP125 Series / GP500 Series / GP1000 Series / GP3000 Series / GP5000 Series Filling Range 30-125ml, 50-500ml, 100-1000ml, 500-3000ml, 1000-5000ml Filling Nozzle 4 6 8 10 12 Filling Capacity
(Based on 1000ml)≤1200 BPH ≤1800 BPH ≤2400 BPH ≤3000 BPH ≤3600 BPH Filling Accuracy ≤+/-0.5% Voltage AC220V/380V 50-60Hz, special voltage customizable Air Pressure 0.5-0.8 MPa Power 2.0-3.5KW 2.0-4.0KW 2.5-4.5KW 3.0-5.5KW 3.0-6.5KW Recommended Liquid Filling Line
A complete liquid filling line can include bottle unscrambler, servo piston filling machine, cap sorting, automatic capping machine, labeling machine, date printer, carton packing and conveyor connection.
Need an automatic liquid filling solution? Contact Grepack with your liquid sample, bottle size and target speed. We will help you choose the right filling machine and complete line layout.
